Beam Extruder Tool

Beam Extruder uses an external excel spreadsheet where you define start points for the beam segments and which profile to use. Custom profiles can be created in Tekla Structures.The extension can create layout points along all part edges, additionally it comes bundled with a plugin called EdgeMeasurement which can be used to create layout points along specific part edges only.This tool creates consecutive beams, a polybeam or an item with any profile and can be used for bridge modelling.
